Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S

Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S
Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S

Large Image :  Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S

Product Details:
Place of Origin: China
Brand Name: SUNNY
Certification: 3C,CE
Model Number: SN-XDH
Payment & Shipping Terms:
Minimum Order Quantity: 1 Pcs
Price: $7000~12000
Packaging Details: container
Delivery Time: 15~30 days
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 500 Set/ Year

Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S

Description
Name: Freight Elevator Rated Speed: 0.25~1.0m/s
Loading: 1000~5000kg Pit Depth: 1600~1800mm
Keywords: Passenger Elevator Lift Flooring: PVC
Material: Stainless Steel 304 Car Wall: Mirror Stainless Steel
Model: Freight Elevator Type: Freight Elevator
High Light:

high speed lift

,

airport walking escalator

Freight elevator with his gravity big beautiful and durable / Rated speed 0.25~1.0m/s

Compared with traditional lifts, freight elevator, with his gravity big, beautiful and durable, energy efficient and other characteristics, can be  maximized to meet the various places of different cargo needs. Using leading technology and environmental control measures, we must adhere to the safe carriage. By virtue of superior carrying performance and long service life, it can practice industrial transport mission by technology.

Oversized load
12000kg oversized load, easy to deal with the different needs of different places.

Safe and reliable
Using multiple secure devices, it can keep people and cargo security and achieve a smooth carrying in the whole journey.

Sturdy profiles
Full steel cage materials, compared to the general profile, greater firmness to withstand severe impacts.


Loading
capacity(kg)
Rated
speed(m/s)
Door opening
width(mm)
Door opening
height(mm)
Car size(mm)
Width Depth Height
Hoistway size(mm)
Width Depth
Machine room size(mm)
Width Depth
Top floor
height(mm)
Pit
depth(mm)
Max.travelling
height(mm)
1000 0.5 side opening
1300
2100

1300

1750

2300

2400

2250

3100

3800

4300 1600 44
0.63 side opening
1300
2100

1300

1750

2300

2400

2250

3100

3800

4300 1600 56
1.0 side opening
1300
2100

1300

1750

2300

2400

2250

3100

3800

4300 1600 76
1600 0.5 side opening
1500
2100

1500

2250

2300

2700

2750

3400

4500

4300 1600 44
0.63 side opening
1500
2100

1500

2250

2300

2700

2750

3400

4500

4300 1600 56
1.0 side opening
1500
2100

1500

2250

2300

2700

2750

3400

4500

4300 1700 76
2000 0.5 side opening
1500
2100

1500

2700

2300

2700

3200

3400

4500

4300 1600 44
1.0 side opening
1500
2100

1500

2700

2300

2700

3200

3400

4500

4300 1700 76
3000 0.5 double-folede
center opening
2200
2100

2200

2600

2300

3600

3100

3600

4400

4300 1700 44
4000 0.25 double-folede
center opening
2200
2300

2200

3200

2500

3800

3700

3800

4100

4500 1800 44
0.5 double-folede
center opening
2200
2300

2200

3200

2500

3800

3700

3800

4100

4500 1800 44
5000 0.25 double-folede
center opening
2400
2300

2400

3600

2500

4100

4100

4100

4500

4500 1800 44
7000 0.5 double-folede
center opening
2400
2300

2400

3600

2500

4100

4100

4100

4500

4500 1800 44



Freight elevator

Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S 1



Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S 2



Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S 3



Beautiful Durable Freight Elevator Building Lifts Elevators 0.25~1.0m/S 4



FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
